Installation and Communication
28
Mounting and Removing the FX Series Readers
Mounting Tips
Mount the reader in any orientation. Consider the following before selecting a location for the FX7500 and
FX9600 readers:
Mount the reader indoors, in operating range and out of direct sunlight, high moisture, and/or
extreme temperatures.
Mount the reader in an area free from electromagnetic interference. Sources of interference include
generators, pumps, converters, non-interruptible power supplies, AC switching relays, light
dimmers, and computer CRT terminals.
Ensure that any cable losses between the reader and antenna are taken into account to ensure the
desired level of system performance.
Ensure that power can reach the reader.
The recommended minimum horizontal mounting surface width is 7 1/2 inches for the FX7500 only.
However, the unit can mount on surfaces as narrow as 6 inches (in locations where unit overhang
is not an issue). For vertical mounting the unit can mount on a surface as small as 6 inches by 6
inches.
Mount the reader onto a permanent fixture, such as a wall or a shelf, where it is not disturbed,
bumped, or damaged. The recommended minimum clearance on all sides of the reader is five
inches.
Use a level for precise vertical or horizontal mounting.
Mounting the FX7500 With a Mounting Plate
1. Position the mounting plate on a flat surface (wall or shelf). Position the release tab on the top. See
Figure 15.
2. Mark the hole locations using the mounting plate as a guide. See Figure 15. Remove the mounting
plate and drill holes (appropriate for the surface material) at the marked locations.
WARNING: For Mounting in Environmental Air Handling Space (EAHS): Do not install the Bracket, Cables
in the EAHS unless they are suitable for use in EAHS per UL 2043.
NOTE: The Mounting Plate section applies to the FX7500 RFID Fixed Reader only.
NOTE: For wood surfaces, drill two 1/8" diameter by 7/8" deep holes. For drywall/masonry surfaces,
drill two 3/16" diameter by 7/8" deep (min) holes and install using the provided anchors.
