Getting Started
21
FX7500 Parts
Figure 9 FX7500 RFID Reader Rear Panel Connections
Figure 10 FX7500 RFID Reader
Port 1 Port 2 Port 3 Port 4 GPIO 24 VDC
Antenna Ports (Four Ports, Reverse TNC)
USB
Client
Power
GPIO
10/100BaseT
Ethernet (with PoE)
Reset
USB
Host
PWR AC T V STAT
APP
Antenna Ports (Reverse TNC)
LEDs
Rear Panel
CAUTION:Use only parts provided with the FX7500 RFID readers, or Zebra approved/recommended parts.
Substituting other cables or parts can degrade system performance, damage the reader,
and/or void the warranty.

Table of Contents

Other manuals for Zebra FX7500

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra FX7500 and is the answer not in the manual?

Zebra FX7500 Specifications

General IconGeneral
InterfaceUSB
Product colorWhite
LED indicatorsActivity, Power, Status
Housing materialAluminium, Metal, Plastic
Battery type-
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)-20 - 55 °C
Operating relative humidity (H-H)5 - 95 %
Harmonized System (HS) code84719000
Weight and Dimensions IconWeight and Dimensions
Depth43.2 mm
Width149.9 mm
Height195.6 mm
Weight860 g
