Zebra FX7500 Integration Guide

Technical Specifications
125
Shock and Vibration
FX7500
FX9600
MIL-STD-810G
MIL-STD-810G
Connectivity
Communications 10/100 BaseT Ethernet (RJ45) w/ PoE support, PoE+, USB Client (Type B),
USB Host (Type A)
General Purpose I/O
FX7500
FX9600
2 inputs, 3 outputs, optically isolated (terminal block)
External 12V ~ 48 VDC power available for GPIO
4 inputs, 4 outputs, optically isolated (terminal block)
External 12V ~ 24 VDC power available for GPIO
Power
FX7500
FX9600
PoE (802.3af), PoE+ (802.3at)
12 VDC to 48 VDC, or 24 VDC Universal Power Supply
PoE (802.3af), PoE+ (802.3at)
12 VDC to 24 VDC, or 24 VDC Universal Power Supply
Antenna Ports
FX7500
FX9600
FX7500-2: 2 mono-static ports (reverse polarity TNC)
FX7500-4: 4 mono-static ports (reverse polarity TNC)
FX9600-4: 4 mono-static ports (reverse polarity TNC)
FX7500-8: 8 mono-static ports (reverse polarity TNC)
Hardware/OS and Firmware Management
Memory Flash 512 MB; DRAM 256 MB
Operating System Linux
Firmware Upgrade Web-based and remote firmware upgrade capabilities
Management Protocols RM 1.0.1 (with XML over HTTP/HTTPS and SNMP binding)
Network Services DHCP, HTTPS, FTPS, SFPT, SCP, SSH, HTTP, FTP, SNMP and NTP
Network Stack IPv4, IPv6
Security Transport Layer Security Ver. 1.2, FIPS 140-2 Level 1
Air Protocols EPCglobal UHF Class 1 Gen2, ISO 18000-6C
Frequency (UHF Band) Global Reader: 902 MHz to 928 MHz (Maximum, supports countries that
use a part of this band)
865 MHz to 868 MHz
US (only) Reader: 902 MHz to 928 MHz
Table 8 Technical Specifications (Continued)
Item Description

Zebra FX7500 Specifications

General

Interface	USB
Product color	White
LED indicators	Activity, Power, Status
Housing material	Aluminium, Metal, Plastic
Battery type	-
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84719000

Weight and Dimensions

Depth	43.2 mm
Width	149.9 mm
Height	195.6 mm
Weight	860 g
