Zebra VC80 User Manual

5 - 2 VC80 User Guide
Touchscreen
The VC80 is equipped with a resistive touchscreen.
Operation of the resistive touchscreen is recommended with:
• Clean, dry fingers.
• Clean, dry, soft gloves.
• Suitable touch stylus (plastic or wood, rounded tip).
CAUTION - Keep the touchscreen clean (see Touchscreen Cleaning on page 5-1).
- Do not apply adhesives to the surface.
- Avoid high voltage and/or static charge.
- Do not use ball point pens, writing utensils, tools, or sharp objects.
- Touch the panel with your finger or stylus only to ensure normal operation.
- Operate in a stable environment. Abrupt variation of temperature and humidity may cause malfunction.
- Avoid applying excessive activation force or sudden impact on the touchscreen surface.

Zebra VC80 Specifications

General

Display diagonal	10.4 \
Display resolution	1024 x 768 pixels
Touchscreen technology	Resistive
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Processor cache	2 MB
Processor cores	4
Processor model	E3845
Processor family	Intel Atom®
Processor frequency	1.91 GHz
Internal memory	4 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	mSATA
Storage media	SSD
Total storage capacity	128 GB
Certification	RoHS, WEEE, REACH compliant, IEC UL94-V0
Number of speakers	1
Card reader integrated	No
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Quantity per pack	1 pc(s)
RS-232 ports	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Operating system installed	Windows 10 IoT Enterprise
Operating system architecture	64-bit
Harmonized System (HS) code	84715000

Weight and Dimensions

Depth	90 mm
Width	235 mm
Height	265 mm
Weight	3900 g
