Zebra VC80 User Manual

CHAPTER 4 SOFTWARE WINDOWS 10
Introduction
This chapter provides software information and instruction for the VC80 with Windows 10.
Microsoft Windows Setup and Configuration
After the system files are processed, Microsoft Windows loads. Standard Windows configuration options apply to
the VC80. Configuration options are located in the System Tray or the Control Panel. For example, use the System
Tray to adjust the time, date or volume level and the Control Panel to add, delete or modify software.
Folder Structure
Microsoft Windows is installed in the \Windows folder. For information on the folder structure, refer to the
commercially available Microsoft Windows OS Reference Guide.

Zebra VC80 Specifications

General

Display diagonal	10.4 \
Display resolution	1024 x 768 pixels
Touchscreen technology	Resistive
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Processor cache	2 MB
Processor cores	4
Processor model	E3845
Processor family	Intel Atom®
Processor frequency	1.91 GHz
Internal memory	4 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	mSATA
Storage media	SSD
Total storage capacity	128 GB
Certification	RoHS, WEEE, REACH compliant, IEC UL94-V0
Number of speakers	1
Card reader integrated	No
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Quantity per pack	1 pc(s)
RS-232 ports	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Operating system installed	Windows 10 IoT Enterprise
Operating system architecture	64-bit
Harmonized System (HS) code	84715000

Weight and Dimensions

Depth	90 mm
Width	235 mm
Height	265 mm
Weight	3900 g
