CHAPTER 1 GETTING STARTED
Introduction
The VC80 is a rugged, vehicle mounted computer running Microsoft Windows Embedded Standard 7 and Windows
Professional for Embedded Systems operating systems. Wireless communications are supported over a 802.11
WLAN network. The Bluetooth module supports Bluetooth printers and scanners. The VC80 can be used with or
without an external keyboard. There are six programmable macro keys on the front bezel and when used with the
Blue modifier key, provides six additional programmable keys.
The VC80 is intended for use in commercial and industrial applications with a focus on real time wireless data
transactions with options suiting materials handling applications in warehouses, manufacturing facilities, ports,
yards, and freezers.
Unpacking
Carefully remove all protective material from the device and save the shipping container for later storage and
shipping.
Inspect the equipment for damage. If any equipment is missing or damaged, contact the Zebra Support Center
immediately. See Service Information on page xii for contact information.
Removing the Protective Film from the Display
The front display of the VC80 is protected during transport by a transparent film. This film should remain on the
front display during assembly to avoid damage to the front display surface. Only remove the film once all of the
assembly work has been completed.
WARNING ! Before operating the unit for the first time, carefully read Safety on page 1-2.
NOTE Configure the computer before fastening it to machines or vehicles.

Zebra VC80 Specifications

General

Display diagonal	10.4 \
Display resolution	1024 x 768 pixels
Touchscreen technology	Resistive
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Processor cache	2 MB
Processor cores	4
Processor model	E3845
Processor family	Intel Atom®
Processor frequency	1.91 GHz
Internal memory	4 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	mSATA
Storage media	SSD
Total storage capacity	128 GB
Certification	RoHS, WEEE, REACH compliant, IEC UL94-V0
Number of speakers	1
Card reader integrated	No
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Quantity per pack	1 pc(s)
RS-232 ports	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Operating system installed	Windows 10 IoT Enterprise
Operating system architecture	64-bit
Harmonized System (HS) code	84715000

Weight and Dimensions

Depth	90 mm
Width	235 mm
Height	265 mm
Weight	3900 g
