6 - 8 VC80 User Guide
MT43XX RAM Mount
The VC80 may be installed using an articulating RAM Mount (Model MT43XX – 4 in. or 12 in. arm) secured to
either a VESA or circular base.
The RAM articulating mount can be installed in a variety of orientations (see Figure 6-3 on page 6-9). Select the
best orientation for the specific application. Preferred orientations maintain the center of mass of the computer
assembly, directly over the center of the base.
For detailed mount installation information, refer to the instructions included with the mount kit.
Figure 6-2 Orientation of Vehicle-Mount Assembly
IMPORTANT To avoid injury, this device must be properly secured when in a moving vehicle.
Keep this device away from magnetic fields.
Do not place the computer near a television or radio receiver.
Do not disassemble the VC80 computer as there are no user-serviceable parts inside.
IMPORTANT The operator can easily adjust the tilt and rotation of the VC80. Use care to avoid operator
injury or equipment damage if the computer slips due to a loosened hand screw.

Zebra VC80 Specifications

General

Display diagonal	10.4 \
Display resolution	1024 x 768 pixels
Touchscreen technology	Resistive
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Processor cache	2 MB
Processor cores	4
Processor model	E3845
Processor family	Intel Atom®
Processor frequency	1.91 GHz
Internal memory	4 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	mSATA
Storage media	SSD
Total storage capacity	128 GB
Certification	RoHS, WEEE, REACH compliant, IEC UL94-V0
Number of speakers	1
Card reader integrated	No
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Quantity per pack	1 pc(s)
RS-232 ports	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Operating system installed	Windows 10 IoT Enterprise
Operating system architecture	64-bit
Harmonized System (HS) code	84715000

Weight and Dimensions

Depth	90 mm
Width	235 mm
Height	265 mm
Weight	3900 g
