Zebra VC80 User Manual

1 - 6 VC80 User Guide
LED Indicators
Table 1-2 VC80 LED Indicators
Configuring GPS
For VC80 configurations with GPS, see GPS on page 3-31 for information on setting up and configuring the GPS
with U-Center.
Green/Amber
LED
Red LED Blue LED Description
Off Off Off No external power and the VC80 is not running on UPS.
Amber On Off Off External power is available but the VC80 is not turned On
(in shutdown or hibernate mode). The VC80 is ready to
be turned on and is currently charging the UPS battery.
Green On Off External power is available and the VC80 is turned ON.
The UPS battery is charging.
Green Flashing
(50% Duty
Cycle On at
500ms Period)
External power is removed. The VC80 is running on UPS
battery power.
Green Flashing
(25% Duty
Cycle On at
4000ms Period)
Off Off The VC80 is in sleep mode.
Green On Off Off Bezel keyboard keys: M1, M2, M3, M4, M5, M6
Green On Off On Bezel keyboard keys: M7, M8, M9, M10, M11, M12
Flashing Red
(50% Duty
Cycle On at
500ms
Period)
Temperature related warning or error event in the
system. Average of radio card and audio codec tempera-
ture readings is either <-35° C or > +65° C. No action is
required if the OS is running. If the OS is in Sleep or
Hibernate state, then the EC should switch the VC80 Off.
Off On Off Warm up condition. The average of radio card and audio
codec temperature readings is between -35° C and 0° C.
The OS is not running. The Power Button is disabled.
NOTE For fields in the above table without LED information, the LED can be On or Off dependent on user
actions and ambient temperature.

Zebra VC80 Specifications

General

Display diagonal	10.4 \
Display resolution	1024 x 768 pixels
Touchscreen technology	Resistive
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Processor cache	2 MB
Processor cores	4
Processor model	E3845
Processor family	Intel Atom®
Processor frequency	1.91 GHz
Internal memory	4 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	mSATA
Storage media	SSD
Total storage capacity	128 GB
Certification	RoHS, WEEE, REACH compliant, IEC UL94-V0
Number of speakers	1
Card reader integrated	No
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Quantity per pack	1 pc(s)
RS-232 ports	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Operating system installed	Windows 10 IoT Enterprise
Operating system architecture	64-bit
Harmonized System (HS) code	84715000

Weight and Dimensions

Depth	90 mm
Width	235 mm
Height	265 mm
Weight	3900 g
