6 - 10 VC80 User Guide
MT4200 Quick Release Mount
The MT4200 Quick Release Mount allows a removal without the need for tools.
Assembling MT4200
To assemble the MT4200 Quick Release mount:
1. Place the back mounting plate hooks into the base plate slots.
2. Snap spring clips into place.
Figure 6-4 MT4200 Quick Release Mount Assembly
Spring
Clip
MT4200
Back Mounting
Plate Hooks
MT4205 Base
Plate Slots
