Zebra VC80 User Manual

6 - 2 VC80 User Guide
Mounts
MT4200 Quick release mount
MT4205 Mounting plate for the MT4200 quick release mount
MT4210 Adaptor bracket kit for 82XX quick release mount
MT4510 RAM rectangular base with 2.25" rubber ball
MT4301 RAM mount, 4" arm
MT4302 RAM mount, 12" arm
MT3501 VESA base (for 4" or 12" RAM arm)
MT3502 Circular base (for 4" or 12" RAM arm)
MT3505 Clamp base (for 4" or 12" RAM arm), 2" max. width
MT3507 Clamp base (for 4" or 12" RAM arm), 3" max. width
MT3509 Rail base (for 4" or 12" RAM arm), 1-1/4" to 1-7/8"
MT3510 Rail base (for 4" or 12" RAM arm), 2" to 2 1/2"
KT-SCANMNT-VC80-R Side mounted holder for scanner
KT-KYBDTRAY-VC80-R Keyboard mounting tray (includes tilting arms, knobs and screws) for VC80 and iKey
keyboards
KT-KYBDMNT-VC80-R Function/Numeric keypad side mount bracket
Table 6-1 Accessories
Model Number Accessory

Zebra VC80 Specifications

General

Display diagonal	10.4 \
Display resolution	1024 x 768 pixels
Touchscreen technology	Resistive
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Processor cache	2 MB
Processor cores	4
Processor model	E3845
Processor family	Intel Atom®
Processor frequency	1.91 GHz
Internal memory	4 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	mSATA
Storage media	SSD
Total storage capacity	128 GB
Certification	RoHS, WEEE, REACH compliant, IEC UL94-V0
Number of speakers	1
Card reader integrated	No
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Quantity per pack	1 pc(s)
RS-232 ports	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Black
Operating system installed	Windows 10 IoT Enterprise
Operating system architecture	64-bit
Harmonized System (HS) code	84715000

Weight and Dimensions

Depth	90 mm
Width	235 mm
Height	265 mm
Weight	3900 g
