Reference Table of Screens and Menu Items
Table 66 TThe List of the Settings
Screens & Tabs
Items
Product selection screen
Product setting screen
Product
edit tab
Page 39
Product name
Product code
Product setting tab
Page 40
Sensitivity screen
FAIL
limit screen
Page 40
FAIL limit I
FAIL limit Q
FAIL limit P
Under limit
Inspection phase screen
Phase
tab
Page 42
Phase I
Phase Q
Phase P
Phase
tracking tab
Page 42
Phase tracking
Reset phase tracking
Init. phase mode
Number of Init. phase
Value of phase tracking
FAIL
behavior screen
Page 43
Consecutive FAIL stop
Consecutive FAIL count
Stop belt mode
Stop belt distance
Delay time of detection
DO
map screen
Page 44
PASS
FAIL 1
FAIL 2
FAIL 3
FAIL 4
Cal. PASS
Cal. FAIL 1
Cal. FAIL 2
Cal. FAIL 3
Cal. FAIL 4
Error alarm
FAIL stop
Inspecting
Init. phase tracking
Rotate CW
Rotate CCW
No rotation
Calibration
Setting sensitivity
CPU run
DO
behavior screen
Page 45
Delay time
Hold time
Polarity
C
alibration setting screen
Page 46
Number of phase adjustment
Number of PASS
Number of FAIL
