9 General-Purpose I/O Terminals - 8.4 Address for Modbus
63
9
9.
General-Purpose I/O Terminals
WARNING
Shut down the power before connecting I/O cables.
If the system is not shutdown, it may cause an electrical shock or damage parts.
CAUTION
When opening the I/O box, open it slowly and carefully, so as not to pull the cable. Entwined
cables may cause damage to connectors.
Table 112 GGeneral Purpose Input/Output Table
Printed Name
Omitted Name
Signal Name
EMG
TM5
ENG - IN 1
ENG IN 1
Emergency stop input signal 1
ENG - IN 2
ENG IN 2
Emergency stop input signal 2

ENG - COM
ENG COM
Emergency stop input signal COM

ENG - OUT
ENG OUT
Emergency stop output signal

ENG - OUT
ENG OUT
Emergency stop output signal

INPUT
TM4
INPUT - 1
DI 1
General purpose input signal 1
INPUT - 2
DI 2
General purpose input signal 2

INPUT - 3
DI 3
General purpose input signal 3

INPUT - 4
DI4
General purpose input signal 4

INPUT - COM
IN COM
General purpose input signal COM

TM3
GND
GND
24 V ground
24V
24V
24 V power source

GND
GND
24 V ground

24V
24V
24 V power source

GND
GND
24 V ground

OUTPUT
TM2
OUTPUT - 5
DO 5
General purpose output signal 5
OUTPUT - 6
DO 6
General purpose output signal 6

OUTPUT - 7
DO 7
General purpose output signal 7

OUTPUT - 8
DO 8
General purpose output signal 8

OUTPUT - COM
OUT2 COM
General purpose output signal COM

OUTPUT
TM1
OUTPUT - 1
DO 1
General purpose output signal 1
OUTPUT - 2
DO 2
General purpose output signal 2

OUTPUT - 3
DO 3
General purpose output signal 3

OUTPUT - 4
DO 4
General purpose output signal 4

OUTPUT - COM
OUT1 COM
General purpose output signal COM

