AMT/PTD/PBX/0058/4/6/EN Installation and Maintenance Manual - Aastra 5000
Page 434 01/2011 Maintenance
SHEET E-10REPLACING AN IUCV-D CARD
AVAILABILITY
• Partial mission capable
OPERATORS (s)
• 1 operator on site
DURATION
• 2 minutes
INGRÉDIENT(S)/CONSOMMABLE(S)
•N/A
Table 17:
OPERATION DETAILS OF THE OPERATION / COMMENTS
• Back up the customer
configuration.
• Precautionary operation to be carried out if there is no existing
copy (which is the case when previous installation operations
have been carried out and the procedures followed).
• Refer to [1]
• In the case of remote operation, contact the remote operator
before starting any operation.
• Disable the IUCV-D card
from the AMP.
Refer to the document AMP Operating manual.
• Disconnect the cables. • Disconnect the external cables from the card and mark the
cables for refitting.
• Pull out the card from its
slot.
• Use the 1/4 turn locks to remove the card from its slot
(see Figure 4.1.
Nota : The IUCV-D card can be removed from an
operational AXD iPBX.
Nota : The i-button becomes inaccessible when the IUCV-
D card is removed. The locking software checks
every hour whether the i-button module is available.
If the software makes this check while the IUCV-D
is being replaced, some functions will be locked
dynamically (the directory, for instance). Simple call
(also for IP sets) remain operational.
• Recover the i-button
module.
• Recover, on the IUCV-D card, the i-button module containing the
system's identifier.
