Required parts
Drive module standard parts
• Drive module
• Top guide plate
• Fastening bracket
• Grounding busbar
• Pedestal guide plate
• Telescopic extraction and insertion ramp
• Fastening screws in a plastic bag
• External control unit
Drive module options
DescriptionQty (pcs)Option code
Full power cabling panels1+H381
External control unit1+P906
Rittal parts / Alternative ABB parts
DescriptionQty (pcs)Rittal part code
Enclosure without mounting plate, bottom plates and side
panels
1VX 8406.000
Side panels for the enclosure1VX 8106.245
Spacers for roof plate / ABB roof1DK 7967.000
(one set = four pieces)
ABB 3AUA0000125201 (IP20)
ABB 3AUA0000114967 (IP42)
Punched section with mounting flange, outer mounting level
for 600 mm horizontal
5VX 8617.030
Punched section with mounting flange, outer mounting level
for 400 mm horizontal
3VX 8617.010
Air filter 323 mm × 323 mm. Remove the filter mat according
to the manufacturer’s instructions.
4 /
2
SK 3243.200 /
ABB 3AUA0000117002 (IP20)
ABB 3AUA0000117007 (IP42)
Support rail (alternative to a customer-made bottom plate)3TS 4396.500
Customer-made parts (not ABB or Rittal products)
DescriptionQty (pcs)Dimension drawing code
Air baffles
See section Air baffles for option +H381 in Rittal VX25 400 mm
wide enclosure installation (page 217) for the dimension
drawings of the air baffles required in the cabinet.
23AXD50000437368
Cabinet bottom plate (alternative to Rittal support rails)
See section Bottom plate for option +H381 in Rittal VX25
400 mm wide enclosure installation (page 218) for the dimen-
sion drawing of a customer-made bottom plate.
13AXD50000433988
Required tools
• Set of screw drivers (Torx and Pozidriv)
• Set of metric magnetic-end hexagon sockets
• Torque wrench with a 500 mm (20 in) or 2 × 250 mm (2 × 10 in) long socket
extension.
122 Installation example with full cabling panels (option +H381)
