ABB ACS880-107

Output ratings
Input
ratings
Frame
size
Inverter
unit
type
ACS880-
107- …
Heavy-duty use
Light-overload
use
No-overload use
P
Hd
I
Hd
P
Ld
I
Ld
S
N
P
N
I
2
I
max
I
1
kWAkWAkVAkWAAA
56059871076895680080012009002×R8i0800A-7
710770900989123110001030155011592×R8i1030A-7
80087510001123139811001170176013162×R8i1170A-7
1100115214001478184014001540231017333×R8i1540A-7
1200130216001670208016001740261019583×R8i1740A-7
1600172020002208274920002300345025884×R8i2300A-7
2000213924002746341828002860429032185×R8i2860A-7
240055832003283408732003420513038486×R8i3420A-7
2800298536003830476936003990599044897×R8i3990A-7
3200341140004378545044004560684051308×R8i4560A-7
3600383748004925613148005130770057719×R8i5130A-7
40004264520054726812560057008550641310×R8i5700A-7
￭
Definitions
Nominal AC supply voltage of drive system U
n
Nominal rms input current I
1
Nominal output current (available continuously with no over-loading) I
2
Typical motor power in no-overload use P
n
The horsepower ratings are typical NEMA motor sizes at 460 V (ACS880-107-xxxxA-5) and
575 V (ACS880-107-xxxxA-7) respectively.
Apparent power in no-overload use S
n
Continuous rms output current allowing 10% overload for 1 minute every 5 minutes I
Ld
Typical motor power in light-overload use P
Ld
Maximum output current. Available for 10 seconds at start; otherwise as long as allowed by
drive temperature.
I
max
Continuous rms output current allowing 50% overload for 1 minute every 5 minutes I
Hd
Typical motor power in heavy-duty use P
Hd
Note:
• The ratings apply at an ambient temperature of 40 °C (104 °F).
• To achieve the rated motor power given in the table, the rated current of the drive
must be higher than or equal to the rated motor current.
• The DriveSize dimensioning tool available from ABB is recommended for selecting
the drive, motor and gear combination.
144 Technical data
