Control panel7
￭
Overview of the control connections of the BCU control unit
1
2
3
4
5
6
7
F
X
X
F
X
X
F
X
X
X
8
CLOSE
9
10
Control panel.7Analog and digital I/O extension modules and
fieldbus communication modules can be in-
serted into slots 1, 2 and 3.
1
2
3
Fiber optic links to power modules (inverter,
supply, brake or converter)
8Memory unit4
Ethernet port. Not in use.9Slot 4 for RDCO module5
Safety option interface. Only in use for the
inverter units.
10Terminal blocks.6
￭
The ACS-AP-W control panel
The ACS-AP-W is the user interface of the inverter unit, providing the essential controls
such as Start/Stop/Direction/Reset/Reference, and the parameter settings for the
control program.
