ABB ACS880-107

DC
capacitance
Module DC fuse type and quantity
Module type and
quantity
Unit type
μFQtyTypeQty
ACS880-
104-…
ACS880-
107-…
9000020Eaton Bussmann 170M6549100600A-75700A-7
1)
These DC fuses are used for the protection of individual modules. The cubicle also contains larger main DC fuses
that are common to all modules. The size of the main DC fuses depends on the number and size of the inverter
modules. Blown fuses must be replaced with equivalent fuses.
Noise and cooling characteristics
Air flow
Heat dissipation
1)
Noise
level
Inverter unit
type
ACS880-
107-…
Total
Sine filter
(option
+E206)
Inverter unitTotal
Sine fil-
ter
(option
+E206)
Inverter
unit
m
3
/h (cfm)m
3
/h (cfm)m
3
/h (cfm)kWkWkWdB(A)
U
n
= 400 V
–*24 (14)–*0.0747004A8-3
–*24 (14)–*0.0847006A0-3
–*24 (14)–*0.0947008A0-3
–*48 (28)–*0.11390011A-3
–*48 (28)–*0.14390014A-3
–*48 (28)–*0.17390018A-3
–*142 (84)–*0.20630025A-3
–*142 (84)–*0.30630035A-3
–*200 (118)–*0.35710044A-3
–*200 (118)–*0.41710050A-3
–*290 (171)–*0.50700061A-3
–*290 (171)–*0.60700078A-3
–*290 (171)–*0.74700094A-3
–*290 (171)–*0.75700100A-3
–*650 (383)–*1.1710140A-3
–*650 (383)–*1.4710170A-3
–*650 (383)–*1.8710210A-3
–*650 (383)–*2.0710250A-3
–*940 (553)–*2.5720300A-3
–*940 (553)–*3.1720350A-3
3300 (1940)2000 (1180)**1300 (765)9.85.04.8**720470A-3
3300 (1940)2000 (1180)**1300 (765)11.75.06.7**720640A-3
3300 (1940)2000 (1180)**1300 (765)13.05.08.0**720760A-3
3300 (1940)2000 (1180)**1300 (765)17710**720900A-3
6600 (3880)4000 (2350)**2600 (1530)231013**741250A-3
6600 (3880)4000 (2350)**2600 (1530)261016**741480A-3
6600 (3880)4000 (2350)**2600 (1530)341420**741760A-3
150 Technical data
