Dimensions and weights
Contents of this chapter
This chapter contains information on the dimensions and weights of ACS880-107
inverter cubicles.
Frames R1i…R7i
￭
Frames R1i…R5i
Because of the modularity of the design, the width of the cubicle varies between
400…1000 mm according to the number and size of the modules.
The following drawing displays a 400 mm wide cubicle, but the main dimensions apart
from width are also applicable to wider cubicles. For details, refer to the dimension
drawings delivered with the unit.
Option +C128 (cooling air intake through floor of cabinet) extends the cabinet depth
by 130 mm.
Weights
The table shows the estimated maximum weights of R1i…R5i cubicles.
Estimated max. weightCubicle width
Frame size
lbskgmm
530240400
R1i…R4i
685310600
880400800
10704851000
440200300
R5i
705320500
9
Dimensions and weights 165
