Installation checklist
Contents of this chapter
This chapter contains a checklist for the mechanical and electrical installation of the
drive.
Checklist
Examine the mechanical and electrical installation of the drive before start-up. Go
through the checklist together with another person.
WARNING!
Obey the safety instructions of the drive. If you ignore them, injury or
death, or damage to the equipment can occur. If you are not a qualified
electrical professional, do not do installation, commissioning or
maintenance work.
WARNING!
Stop the drive and do the steps in section Electrical safety precautions (page 44)
before you start the work.
Make sure that …
The ambient operating conditions meet the drive ambient conditions specification and enclosure
rating (IP code).
The supply voltage matches the nominal input voltage of the drive. See the type designation label.
The insulation resistance of the input power cable, motor cable and motor is measured according
to local regulations and the manuals of the drive.
The drive cabinet is attached to the floor, and if necessary due to vibration etc, also by its top
to the wall or roof.
The cooling air can flow freely in and out of the drive.
5
Installation checklist 97
