Electrical installation
Contents of this chapter
This chapter describes the electrical installation of the inverter units.
The circuit diagrams in this chapter are simplified presentations. Refer to the diagrams
delivered with the drive system for details.
For more information on cable selection, protections, etc., see ACS880 multidrive
cabinets and modules electrical planning instructions (3AUA0000102324 [English]).
The tightening torques for the electrical connections are listed in the technical data.
Warnings
WARNING!
Obey the safety instructions given in ACS880 multidrives cabinets and
modules safety instructions (3AUA0000102301 [English]). If you ignore
the safety instructions, injury or death, or damage to the equipment
can occur.
If you are not a qualified electrical professional, do not do installation
or maintenance work.
