ABB ACS880-107

Cooling dataDimensions
Nominal
current
Sine filter(s) used
Inverter unit
type ACS880-
107…
Air flow
Heat
dissipation
weightWidth
TypeQty
m
3
/h (cfm)kWkg (lbs)mmA
U
n
= 690 V
See Noise and cooling charac-
teristics (page 150)
340 (750)400447NSIN-0485-610340A-7
340 (750)400447NSIN-0485-610410A-7
840 (1850)1000783NSIN-0900-610530A-7
840 (1850)1000783NSIN-0900-610600A-7
840 (1850)1000783NSIN-0900-610800A-7
960 (2120)10001201NSIN-1380-611030A-7
960 (2120)10001201NSIN-1380-611170A-7
1920 (4230)20002282NSIN-1380-621540A-7
1920 (4230)20002282NSIN-1380-621740A-7
1920 (4230)20002282NSIN-1380-622300A-7
2880 (6350)30003387NSIN-1380-632860A-7
2880 (6350)30003387NSIN-1380-633420A-7
3840 (8470)40004468NSIN-1380-643990A-7
3840 (8470)40004468NSIN-1380-644560A-7
4800 (10580)50005525NSIN-1380-655130A-7
5760 (12700)60006557NSIN-1380-665700A-7
Input power (DC) connection
ACS880-107-xxxxx-3: 513…566 V DC. This is indicated in the type designation
label as typical input voltage level (566 V DC).
Voltage (U1)
ACS880-107-xxxxx-5: 513…707 V DC. This is indicated in the type designation
label as typical input voltage levels (566/679/707 V DC).
ACS880-107-xxxxx-7: 709…976 V DC. This is indicated in the type designation
label as typical input voltage levels (742/849/976 V DC).
TN (grounded) and IT (ungrounded) systems up to 690 V AC.Drive AC supply network
type
Frames R5i…R8i: Corner-grounded systems up to 600 V AC.
Motor connection data
Asynchronous AC induction motors, permanent magnet synchronous motors,
AC induction servomotors and ABB synchronous reluctance (SynRM) motors
Motor types
3-phase symmetrical, Umax at field weakening pointVoltage (U2)
ACS880-107-xxxxx-3: 0…400 V AC. The maximum value (400 V) is a typical
drive input voltage level shown on the type designation label of the supply
unit corresponding to 380…415 V AC.
ACS880-107-xxxxx-5: 0…400/480/500 V AC. The maximum values
(400/480/500 V) are typical drive input voltage levels shown on the type
designation label of the supply unit corresponding to 380…500 V AC.
ACS880-107-xxxxx-7: 0…525/600/690 V AC. The maximum values
(525/600/690 V) are typical drive input voltage levels shown on the type
designation label of the supply unit corresponding to 525…690 V AC.
154 Technical data
