ABB ACS880-107

Transportation
in the protective pack-
age
Storage
in the protective pack-
age
Operation
installed for stationary
use
IEC 60721-3-2:1997IEC 60721-3-1:1997IEC/EN 60721-3-3:2002Contamination
Chemical gases: Class
2C2
Chemical gases: Class
1C2
Chemical gases: Class
3C2
Solid particles: Class 2S2Solid particles: Class 1S3
(packing must support
this, otherwise 1S2)
Solid particles: Class 3S2
(3S1 with IP20). No con-
ductive dust allowed.
2Pollution degree
IEC/EN 60664-1
IEC/EN 60721-3-2:1997IEC/EN 60721-3-1:1997IEC/EN 60721-3-3:2002Vibration
2…9 Hz: max. 3.5 mm
amplitude
10…57 Hz: max.
0.075 mm amplitude
10…57 Hz: max.
0.075 mm amplitude
IEC/EN 61800-5-1
IEC 60068-2-6:2007,
EN 60068-2-6:2008 9…200 Hz: 10 m/s
2
(32.8 ft/s
2
)
57…150 Hz: 1 g 57…150 Hz: 1 g
Units with marine con-
struction (option +C121):
Max. 1 mm (0.04 in)
(5 … 13.2 Hz), max. 0.7 g
(13.2 … 100 Hz) sinusoid-
al
With packing max.
100 m/s
2
(328 ft/s
2
)
11 ms
With packing max.
100 m/s
2
(328 ft/s
2
)
11 ms
Not allowedShock
IEC 60068-2-27:2008, EN
60068-2-27:2009
Cooling
Fans built in inverter modules, exhaust fans in frame R1i…R5i cubicles, and
IP54 cubicles of other frame sizes. Fan in cooling air inlet of control cubicles
(frame R8i and multiples).
Method
Inlet (door): Camfil/airComp 300-50Filter material (IP54)
Outlet (roof): Camfil/airTex G150
See Noise and cooling characteristics (page 150)Air flow
Colors
RAL 7035, RAL 9017.
Materials
￭
Drive
Refer to ACS880 cabinet-installed drives Recycling instructions and environmental
information (3AXD50000153909 [English]).
￭
Packaging of drive
• Plywood
1)
• Wood
• PET (strapping)
• PE (VCI film)
Technical data 161
