ABB DCS800 Hardware Manual

Accessories
121
3ADW000194R0611 DCS800 Hardware Manual f us
Dimensions
X4
1
X11 (F+)
X12 (F-)
1
2
16 75 33.5
935011
7
342
M8
MB_520_a.dsf
Overvoltage Protection
DCF 505-0140/0520-51
DCF 505-1200-51
DCF 506-0140/0520-51
Dimensions in mm
Weight appr. 8 kg
X3 X1
X4 X2
12
SDCS-FEP-1 (500 V)
SDCS-FEP-2 (690 V)
MB_1500_a.dsf
42
145
8.5
355
145
f. M6
M84032
35
8.5
482
20
135
X11
X12
Overvoltage Protection
DCF 506-1200-51
DCF 506-1500-51
DCF 506-1500-71
Dimensions in mm
Weight appr. 20 kg

ABB DCS800 Specifications

General

Control Type	Digital
Supply Voltage	380 ... 690 V AC
Input Voltage Range	380 V to 690 V AC
Control Mode	Torque, Speed
Cooling Method	Air-cooled
Communication Protocols	Modbus, Profibus, CANopen
Communication Options	Ethernet
Protection Class	IP21, IP54
Enclosure Rating	IP00, IP21, IP54
Protection	Overcurrent, Overvoltage, Overtemperature
Ambient Temperature	0 to 40°C
Field Supply	Integrated or External
