ABB DCS800 Hardware Manual

Technical data
77
3ADW000194R0611 DCS800 Hardware Manual f us
The RS232 interface is normally used for setting parameter in the drive via the DWL PC Tool.
The default settings of this interface are as follows:
X8: is needed for SDCS-DSL-4 board which provides the serial communication interface to field
exciters, 12-pulse converters, master-follower and mailbox to other converters.
X9:, X10: and X11: are used for extension IO modules and serial communication interface adapter.
For detailed description see manual Hardware extension RAIO Analog I/O Extension
Hardware extension RDIO Digital I/O Extension
DCS800 61131 Programming target
see chapter SDCS-COM-8 board
X20 (Slot 4) is used for Memory Card, see description IEC61131 programming.
Prepared function of:
Signal level: RS232 (+12V / -12V)
Data format: UART
Message format: Modbus-Protocol
Transmission method: half-duplex
Baudrate: DriveWindow Light: variable
CodeSys download: 38.4 kBaud
FDT firmware download: self-adapting
Number of Data bits: 8
Number of Stop bits: 1
Parity-Bit: odd
X34: Description
1 not connected
2TxD
3RxD
4 not connected
5 SGND Signal ground
6...9 not connected
Slot 1
X9:
Slot 2
X10:
Slot 3
X11:
Slot 4
X20:
RDIO / RAIO x x x
R... Fieldbus adapter x
SDCS-COM-8 x
Second fieldbus RMBA x x
Memory Card x
1
9
5
6
X34:

ABB DCS800 Specifications

General

Control Type	Digital
Supply Voltage	380 ... 690 V AC
Input Voltage Range	380 V to 690 V AC
Control Mode	Torque, Speed
Cooling Method	Air-cooled
Communication Protocols	Modbus, Profibus, CANopen
Communication Options	Ethernet
Protection Class	IP21, IP54
Enclosure Rating	IP00, IP21, IP54
Protection	Overcurrent, Overvoltage, Overtemperature
Ambient Temperature	0 to 40°C
Field Supply	Integrated or External
