ABB X Series User Manual

21060 26M N AA | X SER IE S
G5
| 41
Legend: Solar panel
1
Pipe coupling
4
Solar mounting bracket
2
Extension pipe
5
Solar panel cable
3
U-bolts
6
Flow computer
In the northern hemisphere, position the solar panel facing south. In the southern
hemisphere, position the solar panel facing north.
IMPORTANT NOTE: Position the solar panel correctly before tightening the U-bolts.
Tighten the solar panel mounting hardware.
WARNING – Bodily injury. Install the electrical wiring according to requirements for the
area classification. Refer to the certification drawing indicated on the device’s name tag,
and national and local electrical codes.
Secure the solar panel cable to the pipe:
Do not wrap the cable around the mounting pipe. Run the solar panel cable along the
mounting pipe and use nylon tie wraps to secure the cable.
Gather excess cable and attach it to the mounting pipe using a nylon tie wrap.
Install the cable and cable gland in the enclosure:
Remove a shipping plug from the left side of the flow computer enclosure.
Open the hinged door on the flow computer and visually locate the CHRG terminal block (J5
on the XFC
G5
, J17 on the XRC
G5
).
Remove the cable nut from the cable conduit elbow and insert the cable and conduit ends
through the access hole in the enclosure.
Pull the cable into the enclosure leaving enough cable to reach the CHRG terminal block (J5
on the XFC
G5
, J17 on the XRC
G5
).
Replace the cable nut on the cord and conduit end inside of the enclosure and screw the
nut onto the conduit end finger-tight.
Position the conduit elbow so that moisture will not follow the cable and seep into the
gland. Tighten the cable nut.
Using a small slotted screwdriver, remove the terminal connector from the CHRG terminal
block (J5 on the XFC
G5
, J17 on the XRC
G5
).
NOTICE – Equipment damage or loss of data. Do not insert the connector into the
CHRG terminal block (J5 on the XFC
G5
, J17 on the XRC
G5
) until instructed to do so in section
7.3.2 Connect the charger.
Wire the solar panel cable to the unattached CHRG connector:
a. On the solar panel cable, trim the wire cover ends back ¼ inch (6.35 mm) if necessary.
b. Loosen the terminal connector screws for pins 1 and 2.
c. Insert each solar panel cable wire, as identified by the cable label (+ or -), into the
corresponding CHRG pin (+ or -), as shown in the figure below. Gently tighten the
terminal connector screws.
