11.9.9 Register Map
Name
Address
Direction
Default
Description
I2CCR
E9H
R/W
00H
I2C Control Register
I2CSR
EAH
R/W
00H
I2C Status Register
I2CSAR0
EBH
R/W
00H
I2C Slave Address 0 Register
I2CSAR1
F1H
R/W
00H
I2C Slave Address 1 Register
I2CDR
ECH
R/W
00H
I2C Data Register
I2CSDHR
EDH
R/W
01H
I2C SDA Hold Time Register
I2CSCLR
EEH
R/W
3FH
I2C SCL Low Period Register
I2CSCHR
EFH
R/W
3FH
I2C SCL High Period Register
Table 11.13 I2C Register Map
11.9.10 I2C Register Description
I2C module consists of I2C control register (I2CCR), I2C status register (I2CSR), I2C slave address 0/1 register
(I2CSAR0/I2CSAR1), I2C data register (I2CDR), I2C SDA hold time register (I2CSDHR), I2C SCL low period register
(I2CSCLR), and I2C SCL high period Register (I2CSCHR).
