Abov MC96F8204 Series User Manual

8
MC96F8204
ABOV Semiconductor Co., Ltd.
1.4 MTP programming
1.4.1 Overview
The program memory of MC96F8204 is MTP Type. This flash is accessed by serial data format. There are four
pins(DSCL, DSDA, VDD, VSS) for programming/reading the flash.
Table 1.2 Descriptions of pins which are used to programming/reading the Flash
1.4.2 On-Board programming
The MC96F8204 needs only four signal lines including VDD and VSS pins for programming FLASH with serial
protocol. Therefore the on-board programming is possible if the programming signal lines are considered when the
PCB of application board is designed.
Pin name
Main chip
pin name
During programming
I/O
Description
DSCL
P01
I
Serial clock pin. Input only pin.
DSDA
P00
I/O
Serial data pin. Output port when reading and input port when programming.
Can be assigned as input/push-pull output port.
VDD, VSS
VDD, VSS
-
Logic power supply pin.
