11.10.3 Flash CRC Generator Register Description
The flash CRC generator register consists of flash CRC start address high/middle/low register (FCSARH/
FCSARM/FCSARL), flash CRC end address high/middle/low register (FCEARH/FCEARM/FCEARL), flash CRC
control register (FCCR), flash CRC data high/low register (FCDRH/FCDRL) and flash CRC data In register (FCDIN).
11.10.4 Register Description for Flash CRC Generator
FCSARH (Flash CRC Start Address High Register): 5050H
7
6
5
4
3
2
1
0
–
–
–
–
–
–
–
FCSARH0
–
–
–
–
–
–
–
R/W
Initial value: 00H
FCSARH0
Flash CRC Start Address High
NOTE)
1. Used only to Auto CRC Mode.
FCSARM (Flash CRC Start Address Middle Register): 5052H
7
6
5
4
3
2
1
0
FCSARM7
FCSARM6
FCSARM5
FCSARM4
FCSARM3
FCSARM2
FCSARM1
FCSARM0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
FCSARM[7:0]
Flash CRC Start Address Middle
NOTE)
1. Used only to Auto CRC Mode.
FCSARL (Flash CRC Start Address Low Register): 5054H
7
6
5
4
3
2
1
0
FCSARL7
FCSARL6
FCSARL5
FCSARL4
FCSARL3
FCSARL2
FCSARL1
FCSARL0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
FCSARL[7:0]
Flash CRC Start Address Low
NOTE)
1. Used only to Auto CRC Mode.
