14 On-chip Debug System
14.1 Overview
14.1.1 Description
On-chip debug system (OCD) of MC96F8204 can be used for programming the non-volatile memories and on-chip
debugging. Detail descriptions for programming via the OCD interface can be found in the following chapter.
Figure 14.1 shows a block diagram of the OCD interface and the On-chip Debug system.
