Abov MC96F8204 Series

117
MC96F8204
ABOV Semiconductor Co., Ltd.
11.7.5 Register Map
Name
Address
Direction
Default
Description
ADCCRH
A1H
R/W
00H
A/D Converter Control High Register
ADCCRL
A0H
R/W
00H
A/D Converter Control Low Register
ADCDRH
CFH
R
xxH
A/D Converter Data High Register
ADCDRL
CEH
R
xxH
A/D Converter Data Low Register
Table 11.9 ADC Register Map
11.7.6 ADC Register Description
The ADC register consists of A/D converter data high register (ADCDRH), A/D converter data low register (ADCDRL),
A/D converter control high register (ADCCRH) and A/D converter control low register (ADCCRL).
