10.12.6 Interrupt Register Description
The interrupt register is used for controlling interrupt functions. Also it has external interrupt control registers. The
interrupt register consists of interrupt enable register (IE), interrupt enable register 1 (IE1), interrupt enable register 2
(IE2) and interrupt enable register 3 (IE3). For external interrupt, it consists of external interrupt flag register (EIFLAG),
external interrupt polarity 0 register (EIPOL0), external interrupt flag register (EIFLAG) and external interrupt polarity 1
register (EIPOL1) .
10.12.7 Register Description for Interrupt
IE (Interrupt Enable Register) : A8H
7
6
5
4
3
2
1
0
EA
–
INT5E
–
–
INT2E
INT1E
INT0E
R/W
–
R/W
–
–
R/W
R/W
R/W
Initial value : 00H
EA
Enable or Disable All Interrupt bits
0
All Interrupt disable
1
All Interrupt enable
INT5E
Enable or Disable External Interrupt 0(EINT0)
0
Disable
1
Enable
INT2E
Enable or Disable External Interrupt 12(EINT12)
0
Disable
1
Enable
INT1E
Enable or Disable External Interrupt 11(EINT11)
0
Disable
1
Enable
INT0E
Enable or Disable External Interrupt 10 (EINT10)
0
Disable
1
Enable
