9.2.7 Register Map
Name
Address
Direction
Default
Description
P0
80H
R/W
00H
P0 Data Register
P0IO
88H
R/W
00H
P0 Direction Register
P0OD
94H
R/W
00H
P0 Open-drain Selection Register
P0PU
93H
R/W
00H
P0 Pull-up Resistor Selection Register
P0DB
95H
R/W
00H
P0 Debounce Enable Register
P0FSRH
97H
R/W
00H
P0 Function Selection High Register
P0FSRM
8FH
R/W
00H
P0 Function Selection Mid Register
P0FSRL
96H
R/W
00H
P0 Function Selection Low Register
P1
ACH
R/W
00H
P1 Data Register
P1IO
ADH
R/W
00H
P1 Direction Register
P1OD
AFH
R/W
00H
P1 Open-drain Selection Register
P1PU
AEH
R/W
00H
P1 Pull-up Resistor Selection Register
P1FSR
A7H
R/W
00H
P1 Function Selection Register
P2
C4H
R/W
00H
P2 Data Register
P2IO
C5H
R/W
00H
P2 Direction Register
P2OD
C7H
R/W
00H
P2 Open-drain Selection Register
P2PU
C6H
R/W
00H
P2 Pull-up Resistor Selection Register
Table 9.1 Port Register Map
