176

MC96F8204

ABOV Semiconductor Co., Ltd.

Figure 13.11 Configuration timing when BOD RESET

VDD

Internal nPOR

PAD RESETB

BIT (for Config)

LVR_RESETB

BIT (for Reset)

INT-OSC 8MHz/8

INT-OSC (8MHz)

RESET_SYSB

Config Read

1us X 256 X 28h = about 10ms

1us X 4096 X 4h = about 16ms

“H”

INT-OSC 8MHz / 8 = 1MHz (1us)

“H”

Main OSC Off
