Abov MC96F8204 Series User Manual

19
MC96F8204
ABOV Semiconductor Co., Ltd.
PIN
Name
I/O
Function
@RESET
Shared with
AVREF
I/O
A/D converter reference voltage
Input
P05/AN5/EC1/RESETB
AN0
I/O
A/D converter analog input channels
Input
P00/EINT0/TXD/MOSI/DSDA
AN1
P01/EINT1/RXD/MISO/DSCL
AN2
P02/EINT11/T1O/PWM1O
AN3
P03/EINT12/T2O/PWM2O/SCL
AN4
P04/EINT10/EC2/SDA
AN5
P05/AVREF/EC1/RESETB
AN6
P06/SS/XIN/SXIN
AN7
P07/SCK/XOUT/SXOUT
RESETB
I/O
System reset pin with a pull-up resistor when it is
selected as the RESETB by CONFIGURE
OPTION
Input
P05/AN5/AVREF/EC1
DSDA
I/O
On chip debugger data input/output
Input
P00/AN0/EINT0/TXD/MOSI
DSCL
I/O
On chip debugger clock input
Input
P01/AN1/EINT1/RXD/MISO
XIN
I/O
Main oscillator pins
Input
P06/AN6/SS/SXIN
XOUT
P07/AN7/SCK/SXOUT
SXIN
I/O
Sub oscillator pins
Input
P06/AN6/SS/XIN
SXOUT
P07/AN7/SCK/XOUT
VDD,
VSS
–
Power input pins
–
–
Table 5.1 Normal Pin Description (Concluded)
NOTE)
1. The P16-P17 and P20-P21 are not in the 16-Pin package.
2. The P10-P17 and P20-P21 are not in the 10-Pin package.
3. The P03-P04, P10-P17 and P20-P21 are not in the 8-Pin package.
4. The P05/RESETB pin is configured as one of the P05 and the RESETB pin by the “CONFIGURE
OPTION”.
5. If the P00/AN0/EINT0/TXD/MOSI/DSDA and P01/AN1/EINT1/RXD/MISO/DSCL pins are connected to
an emulator during power-on reset, the pins are automatically configured as the debugger pins.
6. The P00/AN0/EINT0/TXD/MOSI/DSDA and P01/AN1/EINT1/RXD/MISO/DSCL pins are configured as
inputs with an internal pull-up resistor only during the reset or power-on reset.
7. The P06/XIN/SXIN and P07/XOUT/SXOUT pins are configured as a function pin by software control.
