MC96F8204
ABOV Semiconductor Co., Ltd.
LOGICAL
Mnemonic
Description
Bytes
Cycles
Hex code
ANL A,Rn
AND register to A
1
1
58-5F
ANL A,dir
AND direct byte to A
2
1
55
ANL A,@Ri
AND indirect memory to A
1
1
56-57
ANL A,#data
AND immediate to A
2
1
54
ANL dir,A
AND A to direct byte
2
1
52
ANL dir,#data
AND immediate to direct byte
3
2
53
ORL A,Rn
OR register to A
1
1
48-4F
ORL A,dir
OR direct byte to A
2
1
45
ORL A,@Ri
OR indirect memory to A
1
1
46-47
ORL A,#data
OR immediate to A
2
1
44
ORL dir,A
OR A to direct byte
2
1
42
ORL dir,#data
OR immediate to direct byte
3
2
43
XRL A,Rn
Exclusive-OR register to A
1
1
68-6F
XRL A,dir
Exclusive-OR direct byte to A
2
1
65
XRL A, @Ri
Exclusive-OR indirect memory to A
1
1
66-67
XRL A,#data
Exclusive-OR immediate to A
2
1
64
XRL dir,A
Exclusive-OR A to direct byte
2
1
62
XRL dir,#data
Exclusive-OR immediate to direct byte
3
2
63
CLR A
Clear A
1
1
E4
CPL A
Complement A
1
1
F4
SWAP A
Swap Nibbles of A
1
1
C4
RL A
Rotate A left
1
1
23
RLC A
Rotate A left through carry
1
1
33
RR A
Rotate A right
1
1
03
RRC A
Rotate A right through carry
1
1
13
