Abov MC96F8204 Series - Page 80

80
MC96F8204
ABOV Semiconductor Co., Ltd.
IE2 (Interrupt Enable Register 2) : AAH
7
6
5
4
3
2
1
0
–-
–
–
–
INT15E
INT14E
INT13E
–
–
–
–
–
R/W
R/W
R/W
–
Initial value : 00H
INT15E
Enable or Disable Timer 2 Match Interrupt
0
Disable
1
Enable
INT14E
Enable or Disable Timer 1 Match Interrupt
0
Disable
1
Enable
INT13E
Enable or Disable Timer 0 Match Interrupt
0
Disable
1
Enable
IE3 (Interrupt Enable Register 3) : ABH
7
6
5
4
3
2
1
0
–
–
–
INT22E
INT21E
INT20E
–
INT18E
–
–
–
R/W
R/W
R/W
–
R/W
Initial value : 00H
INT22E
Enable or Disable BIT Interrupt
0
Disable
1
Enable
INT21E
Enable or Disable WDT Interrupt
0
Disable
1
Enable
INT20E
Enable or Disable WT Interrupt
0
Disable
1
Enable
INT18E
Enable or Disable ADC Interrupt
0
Disable
1
Enable
