ADCMT 6244 User Manual

6243/44 DC Voltage Current Source/Monitor Operation Manual
4.9 Source Timing and Measurement Timing
4-40
4.9 Source Timing and Measurement Timing
The 6243/44’s timing of source and measurement differs depending on the source mode as shown in Table
4-15.
To ensure accurate measurement, consider the relevant timings for source and measurement, and set the rel-
evant parameters.
Table 4-15 Source Mode and Time Parameters to Be Considered
Source mode Trigger mode
Source and
measurement
Considerable parameter Timing chart
DC
RUN
Asynchro-
nous
Tp, Tm
Table 4-2
HOLD Td, Tm
PLS
Pulse
RUN
Synchronous Tds, Tp, Tw, Td, Tm Table 4-3
HOLD
SWP
DC sweep
Internal
Synchronous Th, Tds, Tp, Td, Tm Table 4-9
External
PSW
Pulse sweep
Internal
Synchronous Th, Tds, Tp, Tw, Td, Tm Table 4-10
External
Tds: Source Delay
Tp: Period
Tw: Pulse Width
Td: Measure Delay
Th: Hold Time
Tm: Measurement Time (Tm = Tit + Tk)
Tit; Integration Time
Tk; Processing Time
