5.2.10 GPIB Code List
5-21
5.2.10 GPIB Code List
5.2.10.1 GPIB Code List
Default indicates the factory default settings, and the initialized statuses resulting from the *RST and RINI
commands.
However, *1 is not initialized by the RINI command and *2 is not initialized by the RINI and *RST com-
mands.
During sweep operation and in the operate status in the DC/pulse mode, commands cannot be accepted
except for those marked with the symbol in Table 5-5.
During DC/PLS operation, those commands marked with the symbol are only accepted in the Hold sta-
tus.
During sweep operation, those commands marked with the symbol are only accepted in the status in
which sweep operation is stopped.
During standby, all the commands can be accepted.
NOTE: The figures in the commands in the GPIB Command List should be treated as 1 English integer char-
acter.
An error results, if MD1 is expressed as MD0001, MD1.000, MD1e-0, etc.
The NR1 to NR3 formats can be used for the numeric character data appearing in <data> such as D
commands, etc.
Table 5-5 GPIB Command List (1 of 9)
Item Command Description Default
Operation
During DC/
PLS operation
During sweep
operation
SOURCE Source mode MD0 DC source mode
MD1 Pulse source mode
MD2 DC sweep source mode
MD3 Pulse sweep source mode
MD? The Source-mode query command
Responds with MD...
Source function VF Voltage source function
IF Current source function
Source function and
source range settings
V3 Voltage source, 320 mV range
V4 Voltage source, 3.2 V range
V5 Voltage source, 32 V and 20 V ranges
V6 Voltage source, 110 V range *a
I-1 Current source, 32 A range *a
I0 Current source, 320 A range
I1 Current source, 3.2 mA range
I2 Current source, 32 mA range
I3 Current source, 320 mA range
I4 Current source, 2 A and 3.2 A ranges
I5 Current source, 10 A range *b
*a: An error occurs for the 6244.
*b: An error occurs for the 6243.
WARNING: The 6243
When the output is set to OPERATE by using the GPIB command or the OPERATE IN/OUT sig-
nal, hazardous voltage is output depending on the setting.
Be careful of electric shocks.
!
