6243/44 DC Voltage Current Source/Monitor Operation Manual
5.2.9 Date Output Format (Talker)
5-20
(b) Fixed-point part and exponent part
The fixed-point part and exponent part are determined by the measurement function, the range
and the number of measurement digits.
(c) String delimiter
A string delimiter is output to set off sets of data.
The string delimiter can be specified by commands.
(d) Block delimiter
A block delimiter is output to indicate the end of one set of data.
The block delimiter can be specified by commands.
Measurement
function
Range
Fixed-point
Exponent part
(three
characters)
5 1/2-digit
measurement
(eight characters)
4 1/2-digit
measurement
(seven characters)
Voltage 320 mV  ddd.ddd  ddd.dd E - 3
3.2 V  d.ddddd  d.dddd E + 0
32 V/20 V  dd.dddd  dd.ddd E + 0
110 V  ddd.ddd  ddd.dd E + 0
Current 32 A  dd.dddd  dd.ddd E - 6
320 A  ddd.ddd  ddd.dd E - 6
3.2 mA  d.ddddd  d.dddd E - 3
32 mA  dd.dddd  dd.ddd E - 3
320 mA  ddd.ddd  ddd.dd E - 3
2 A/3.2 A  d.ddddd  d.dddd E + 0
10 A  dd.dddd  dd.ddd E + 0
Measurement over range +999.999 +999.99 E + 9
Data is not stored when recalling. +888.888 +888.88 E + 8
*1: No data was found when data is read out from the measurement buffer memory.
String delimiter Setting command Initial value
“ , ” Comma SL0
“ ” Space SL1
CR LF SL2
Block delimiter Setting command Initial value
CR LF + EOI DL0
LF DL1
EOI DL2
