6243/44 DC Voltage Current Source/Monitor Operation Manual
5.2.9 Date Output Format (Talker)
5-19
(a) Header
Sub header
Main header
Main header Description
DV Voltage measurement value
DI Current measurement value
EE Data is not stored in the specified recall buffer memory number.
Sub header Description Priority
S Oscillation. 1
R Connects the reverse polarity source. 2
M The limit source 3
O Over the measurement range 4
H The comparison operation result is HI.
5G The comparison operation result is GO.
L The comparison operation result is LO.
N NULL operation value 6
Space Other 7
