2.2.5 Sweep Mode Measurement
2-25
7. Press the EXIT key.
The measurement screen returns.
Setting the current limiter
8. Press the LIMIT key.
The cursor moves to the limiter indication.
9. Press the DIRECT, 3, 0, mA, and ENTER keys in order.
10. Press the LIMIT key.
The cursor moves to the source value.
Setting the sweep source mode
11. Press the MODE key twice.
The sweep mode is selected and SWP appears in the lower right of the screen.
Setting the start value, stop value and step value
12. Press the MENU key.
13. Select SWEEP in the parameter group by rotating the Data knob.
14. Press the key and confirm that Linear (linear sweep) appears as shown below.
15. Rotate the Data knob clockwise by one click and confirm that the Bias Value
shows 0 mV.
L: 0500.0mA
Cursor
L: 30.000mA
Cursor
AZERO
SWEEP
Sweep Type :Linear
AZERO
SWEEP
Bias Value :+000.00mV
