6243/44 DC Voltage Current Source/Monitor Operation Manual
A.3.2 Internal Execution Time (Nominal Values)
A-8
A.3.2 Internal Execution Time (Nominal Values)
(1) Source execution time
Time from the external trigger input to the time when the source value (pulse value, base value, etc.)
start changing
The time from source value change to settle is as shown in Section 4.9.2.
Conditions: Source range: Fixed Range
Measurement range: Fixed. Trigger mode: HOLD or external trigger.
Source delay: 10 s
* The start value for pulse sweep indicates the time from trigger to base value source.
(The time from base value source to start pulse source depends on Hold time.)
(2) Time from external trigger input to measurement and memory store
(3) Switching execution time
• Source function change time: 4.5 ms
• Source range change time
Voltage source function: 3 ms
Current source function: 22.5 ms
• Source polarity change time: 3 ms
• Measurement range change time
Voltage measurement function: 2.5 ms
Current measurement function: 22.5 ms
• Measurement auto range execution time
Voltage measurement function: Integration time + 2.5 ms
Current measurement function: Integration time + 22.5 ms
Source mode Source value Execution time
Pulse Pulse value 17 s
DC sweep Start value 3.8 ms
Step value 17 s
Pulse sweep Start value 3.8 ms
Step value 17 s
Memory mode Execution time
Normal-ON 8 ms
Burst-ON 5 ms
