ADCMT 6244 User Manual

6243/44 DC Voltage Current Source/Monitor Operation Manual
2.2.2 Menu Operations and Parameter Settings
2-13
2.2.2 Menu Operations and Parameter Settings
Menu operations using the MENU key and methods for setting parameters are explained.
Figure 2-6 shows the menu structure of the MENU key.
NOTE: In accordance with the setting status of the 6243/44, parameters which cannot be changed are not dis-
played.
1. Press the MENU key.
The parameter group selection screen appears.
Rotate the Data knob to select the desired parameter group.
2. Press the key.
The parameter item selection screen appears.
Rotate the Data knob to select the desired parameter item.
3. Press the key.
The parameter setting screen appears.
The following 4 parameter setting ways are available.
• When the parameter is indicated by a , the parameter is selected with the
Data knob.
Display example:
• When the parameter is enclosed in [ ], the numeric value can be entered with
the numeric keys and the unit (V/mA or mV/A) key followed by the
ENTER key.
Display example:
• When Execute (Press the DIRECT key) is displayed, press the DIRECT/
ENTER key.
The selected item is executed.
Display example:
AZERO
Sweep Type
Linear
AZERO
Bias Value
[+000.00mV]
AZERO
Load 0
Execute (Press DIRECT Key)
