6243/44 DC Voltage Current Source/Monitor Operation Manual
6.4 GPIB in the TR6143 Mode
6-9
6.4 GPIB in the TR6143 Mode
Explained here are the GPIB commands, output data format, and status byte in the TR6143 mode.
6.4.1 TR6143 Mode GPIB Code List
In the TR6143 mode, the (1) TR6143 unique commands can be used but the (2) commands cannot be used.
Other commands can be used in both the Original Mode and the TR6143 mode.
(1) TR6143 mode unique commands
Table 6-4 shows the TR6143 commands that are not available in the Original Mode. The defaults in-
dicate the status of commands which can be initialized by factory default initialization, DCL, or C
command.
During sweep operation and DC/pulse mode operation, only commands with the symbol in Table
6-4 are accepted.
All the commands are accepted in the standby status.
Table 6-4 TR6143 Mode Unique Commands (1 of 2)
Item Command Description
Default
setting
Operation
6243/44
commands
Remarks
During DC/PLS
operation
During
sweep
operation
Source Source function, source range,
and measurement function
settings
V3 Voltage source, 320 mV range, current measurement V3
V4 Voltage source, 3.2 V range, current measurement V4
V5 Voltage source, 32 V and 20 V ranges, current measurement V5
V6 Voltage source, 110 V range, current measurement V6 *4 *1
I-1 Current source, 32 A range, voltage measurement I-1 *4
(TR6143 mode) I0 Current source, 320 A range, voltage measurement I0
I1 Current source, 3.2 mA range, voltage measurement I1
I2 Current source, 32 mA range, voltage measurement I2
I3 Current source, 320 mA range, voltage measurement I3
I4 Current source, 2 A and 3.2 A ranges, voltage measurement I4
I5 Current source, 10 A range, voltage measurement I5 *5
Source mode C1 DC mode MD0
T0 DC sweep mode automatic trigger MD2, ST0
T1 DC sweep mode external trigger MD2, ST1
Source response RP0 SLOW -*2
RP1 FAST -
Measure-
ment
Auto zero AC0 OFF AZ0
AC1 ON AZ1
Measure-
ment opera-
tion
Comparison operation result
buzzer
UZ3 The buzzer sounds when the comparison operation result is
HI.
BZ1
UZ4 The buzzer sounds when the comparison operation result is
GO.
BZ2
UZ5 The buzzer sounds with the comparison operation result is LO. BZ3
Sweep Sweep repetition number T2 Repeats once SS1
T3 Repeats continuously SS0
Random sweep memory com-
plete setting.
C3 Used when setting the random sweep memory with the N
command.
(Example: N30, D1V, D2V, C3)
P
