6243/44 DC Voltage Current Source/Monitor Operation Manual
1.5 Operational Check
1-12
7. Press the OPERATE key.
The OPERATE lamp lights up and VSVM measurement is performed. (Refer to
Figure 1-10)
8. Confirm that the VM measured value is within 600 V for 0 V in the VS 320
mV range.
9. Press the OPERATE key.
The OPERATE lamp goes off and the 6243/44 enters the standby (output OFF)
mode.
This completes the operational check.
AZERO
VM
VS:+000.00mV L: 0500.0mA *DC
Figure 1-9 VSVM Measurement (In Output OFF Standby)
AZERO
VM+000.002mV
VS:+000.00mV L: 0500.0mA *DC
Figure 1-10 VSVM 320 mV Range 0 V Measurement
