6243/44 DC Voltage Current Source/Monitor Operation Manual
6.4.1 TR6143 Mode GPIB Code List
6-10
Source /
measure-
ment
Time parameter SI SIdd
dd: Period (0 to 99 100 ms)
SP
Trigger T9 DC: Measurement HOLD status: Measurement trigger
Auto trigger sweep: Starts and pauses the sweep.
External trigger sweep: Starts the sweep and triggers signal
output.
*TRG
Auto sweep pause C2 Auto trigger sweep: Pauses the sweep.
GPIB Talker output OM0 The source value is output using ASCII. –
OM1 The measurement value is output using ASCII. – *3
OM2 The measurement value is output in binary. –
OM3 The measurement buffer memory data is output. –
OM4 The operating status is output. –
Header output S4 OFF OH0
S5 ON OH1
The TR6143 status byte
function
S2 The TR6143 status byte is set to level 0. –
S3 The TR6143 status byte is set to level 1. –
The TR6143 mask bit settings MS MSddd
ddd:Mask bit decimal value (0 to 255)
–
Measure-
ment buffer
memory
Measurement buffer-Store OM6 OFF –
OM5 ON (Memory data is output with OM1 and OM2.) –
Measurement buffer-Delete C4 Deletes the measurement buffer memory. RL
Initialization Initialization C The parameter is initialized. *RST
DCL (This will be the default value.)
*1: Command operation differs with the mode.
In the Original Mode, V - is set to voltage source, I -, current source.
In the TR6143 Mode, V - is set to voltage source current measurement, I -, current source voltage measurement.
*2: Since the 6243/44 does not feature a source response switching function, this command will not work even if issued (no error generated).
*3: In the Original Mode, this is fixed as “measurement value is output with ASCII.”
*4: Becomes Syntax Error for 6244.
*5: Becomes Syntax Error for 6243.
-: Becomes Execution Error in the Original Mode.
Table 6-4 TR6143 Mode Unique Commands (2 of 2)
Item Command Description
Default
setting
Operation
6243/44
commands
Remarks
During DC/PLS
operation
During
sweep
operation
To Next Page
