4.9.1 Restrictions on Time Parameters
4-41
4.9.1 Restrictions on Time Parameters
The following explain the setting ranges of the time parameters and interrelated restrictions.
(1) Setting time ranges
Source Delay time: (Tds)
Period (pulse cycle): (Tp)
Pulse Width: (Tw)
Measure Delay time: (Td)
Setting range Resolution
10 s to 600.00 ms 10 s
600.1 ms to 6000.0 ms 100 s
6001 ms to 60000 ms 1 ms
Setting range Resolution
2 ms to 600.00 ms 10 s
600.1 ms to 6000.0 ms 100 s
6001 ms to 60000 ms 1 ms
Setting range Resolution
1 ms to 600.00 ms 10 s
600.1 ms to 6000.0 ms 100 s
6001 ms to 60000 ms 1 ms
Setting range Resolution
300 s to 600.00 ms 10 s
600.1 ms to 6000.0 ms 100 s
6001 ms to 60000 ms 1 ms
