6243/44 DC Voltage Current Source/Monitor Operation Manual
4.9.1 Restrictions on Time Parameters
4-42
Hold Time: (Th)
Auto Range Delay time: (Ta)
Measurement Time: (Tm)
Tm = Tit + Tk
Tit; Integration time
Tk; Processing time (Refer to Section 4.9.3, “Integration Time and Measurement Time.”)
Integration Time: (Tit)
(2) Interrelated time parameter restrictions
The Period (Tp), Measure Delay (Td), Measurement Time (Tm) and Pulse Width (Tw) time parame-
ters are interrelated, and the measurement point changes in accordance with the relations between
these parameters. (Refer to Figure 4-19.)
Setting range Resolution
3 ms to 60000 ms 1 ms
Setting range Resolution
0 ms to 500 ms 1 ms
Setting
Integration time
LF 50 Hz LF 60 Hz
500 s
1 ms
10 ms
1 PLC
10 PLC
100 PLC
500 s
1 ms
10 ms
20 ms
200 ms
2000 ms
500 s
1 ms
10 ms
16.7 ms
166.7 ms
1666.7 ms
