ADCMT 6244 User Manual

6243/44 DC Voltage Current Source/Monitor Operation Manual
5.2.2 GPIB Setup
5-6
(2) GPIB address setting
1. Press the MENU button and rotate the Data knob.
The parameter group selection screen appears as shown below.
2. Press the button.
The parameter selection screen appears as shown below.
3. Select GPIB by rotating the Data knob.
The following screen appears.
4. Press the button.
The current GPIB address appears.
5. Move the cursor with the buttons and change the address by rotating the
Data knob.
6. Press the EXIT button.
The measurement screen returns.
This completes setting of the GPIB address.
AZERO
MENU SELECT
SYSTEM
AZERO
SYSTEM
Line Frequency :50Hz
AZERO
SYSTEM
GPIB :HA - 01
AZERO
GPIB
A - 01
Address
A: Addressable/O: Talk-only switch
H: Header ON/_: Header OFF switch
AZERO
GPIB
HA - 0
H
2
