6243/44 DC Voltage Current Source/Monitor Operation Manual
6.3.1 6243 Default Values
6-6
MEASURE
Integration time 500 s/1 ms/10 ms/1 PLC/10 PLC/100 PLC 1 PLC
Auto zero ON/OFF ON
Measurement digit 5 1/2-digit, 4 1/2-digit 4 1/2-digit
Measurement ON/OFF ON/OFF ON
Display ON/OFF ON/OFF ON
COMPARATOR
Comparator operation ON/OFF OFF
The Comparator upper limit 0.000 mV to 110 V/0.0000 A to 2 A +0000.00 mA
The Comparator lower limit 0.000 mV to 110 V/0.0000 A to 2 A +0000.00 mA
The buzzer the sounds depending
one the Comparator result
ON/OFF OFF
EXT.SIGNAL
The external operation single wire
signal
Operate In (On/Off)/Interlock/Operate Out Operate Off In
Complete output mode Complete Out (Front/End/HI/GO/LO) /Busy (In/Out) Complete Out End
The external single wire output
signal pulse width
20 s/100 s20 s
RANDOM MEMORY Random memory 0 to 4999 [0.00 mV to 110 V/0.000 A to 2 A] +000.00 mV
MEASURE BUFFER
Storing in the measurement
buffer.
ON/OFF OFF
Indicates divergences from the Original Mode.
Table 6-2 List of Defaults in the TR6143 Mode (6243) (2 of 2)
